Description

VRF System Air Conditioners in Bangladesh (SAMSUNG).

SAMSUNG || VRF System Air Conditioners in Bangladesh.

Brand: SAMSUNG
Origin: Korea.
Assembled In: South Korea / China.

Outdoor Unit Capacity: 17.52 Ton / 19.11 Ton / 20.70 Ton / 22.35 Ton / 23.88 Ton
Indoor Unit Options: Wall / Ceiling / Cassette / Duct

Outdoor Unit Models:
AM220FXVAGH/EU: 61.60 KW / 210,200 BTU/HR / 17.52 Ton
AM240HXVAGH/EU: 67.20 KW / 229,300 BTU/HR / 19.11 Ton
AM260FXVAGH/EU: 72.80 KW / 248,400 BTU/HR / 20.70 Ton
AM280KXVAGH/EU: 78.60 KW / 268,200 BTU/HR / 22.35 Ton
AM300KXVAGH/EU: 84.00 KW / 286,600 BTU/HR / 23.88 Ton

Exclusive Warranty:

1. 02 Yrs Compressor – Replacement Guarantee,
2. 01 Yr Spare Parts,
3. 01 Yr After Sales Service (01 Yr free of cost).

Technical Specifications:

1. Power Supply: 380-415V/3Ph/50Hz.
2. Cooling Capacity: 17.52/19.11/20.70/22.35/23.88 Ton.
3. Refrigerant: R-410A (CFC Free).
4. Compressor: Inverter Scroll Type.
5. High COP/Energy Efficient.

Special Features of VRF System Air Conditioners:

1. Easy to Install.
2. Consistent Comfort.
3. Quiet Operation.
4. Heat & Cool Simultaneously.
5. Zoned heating & cooling.
6. Fewer breakdowns/less downtime.
7. Very Low Energy Consumption.
8. R-410a Refrigerants systems.
9. Building management system available.
10. Cordless remote with every indoor unit.
11. 4 kinds of Indoor Unit to choose Cassette, Ceiling, Ducted, Wall Mounted AC.
12. Flash injection technology: SAMSUNG DVM S systems† feature flash injection compressor technology that increases heating performance.
13. Wide Temperature Range: SAMSUNG DVM S systems are designed to operate from 120°F (49°C) ambient to as low as -13°F (-25°C).
14. Ultimate Zoning Solution: SAMSUNG DVM S systems allow for precise temperature control in multiple zones, providing comfort to a wide range of occupants.
15. Wide Variety of Indoor Unit Options: SAMSUNG indoor units offer superior performance, flexible installation, and ease of operation. With over 10 types of indoor units, ranging from 5,000 to 96,000 Btu/h, there are solutions for almost any application.
16. Compact Size of Outdoor Unit: Small outdoor unit footprints allow for installation in applications where space is limited, such as on crowded rooftops, or in tight mechanical closets.
17. Extended Piping Length: DVM S systems offer installation flexibility with extended piping length up to 722 ft., vertical separation up to 361 ft. between the outdoor unit and furthest indoor unit, and 164 ft. between the highest and lowest indoor units.
18. Advanced Commissioning & Service: DVM S systems are equipped with a removable EEPROM chip on the main circuit board to store startup information, system settings, serial number, and other field programmed data. This allows for ease of startup, commissioning, product registration, and future service work when using Samsung service software (S-Net Pro2).
19. VRF System with DX-Type AHU, AHU Kits: In any indoor environment, air quality and efficient air conditioning plays a vital role in maintaining our health, comfort and productivity. Whether it’s a hotel, hospital or museum, every building matters. That’s why DX-AHU with VRF Systems to suit a variety of business applications. The combined system of VRF for building and AHU allows control of room air temperature and humidity delivering many benefits. The installation of DX-AHU with VRF Systems requires minimal effort as there’s no need to add cooling towers, chiller and long piping on the premises. It also allows installation to spaces with limited construction flexibility. Even the maintenance cost of the total solution can be drastically reduced eliminating after care of cooling tower and water piping.

Applications:

1. Apartment Buildings.
2. Hotels and Other Lodging.
3. Office Buildings.
4. Condominium Complexes.
5. Schools and Universities.
6. Dormitories.
7. Data centers.
8. Hospitals & Diagnostic Centers.
9. Manufacturing Plants.
10. Laboratory facilities.
11. Some large retail spaces.
12. Conference Room / Hall Room / Auditorium.
13. Restaurants.
14. Retail Stores.
15. Office Spaces.
16. Anywhere that requires customized heating and cooling over multiple zones.

17. The most common commercial applications for a VRF HVAC system include.



STARWAY AIR CONDITIONING is the leading supplier of VRF System AC of World Renowned Brand GENERAL / DAIKIN / MITSUBISHI / CARRIER / TOSHIBA / SAMSUNG / GREE / MIDEA / HAIER / LG in all over Bangladesh.

Starway Air Conditioning is one of the leading Air Conditioning firm in Bangladesh. Window, Split (Wall/Ceiling/Cassette/Floor Stand), Duct, Package, VRF, AHU, Air and Water cooled Chillers all types of SAMSUNG AC is Available….

Also Please follow us on our Facebook/Twitter/Linkedin/Instagram Page to get all the latest updates and promotions:

https://web.facebook.com/starwaygroup/

https://twitter.com/StarwayGroup

https://bd.linkedin.com/in/starwaygroup

https://www.instagram.com/starwaygroup/

VRF System: ? ? ?

Variable refrigerant flow (VRF), also known as variable refrigerant volume (VRV), is an HVAC technology invented by Daikin Industries, Ltd. in 1982. Variable Refrigerant Flow (VRF) systems consist of outdoor units connected to multiple indoor units via refrigerant piping to provide cooling and heating to individual zones. The outdoor units can modulate capacity based on the requirements of the individual zones, thus saving energy by not always running at 100% capacity and improving occupant comfort by maintaining temperature as needed in each individual zone.
